Magnetic Sign Ballast - 6-20 ft. Total Lamp Length - (2-4 Lamps)
120 Volt - Sola E620-F-2345088-TP
SKU:
BS-E620F2345088TP
Details
Description
The Sola E620-F-2345088-TP fluorescent sign ballast operates two to four T12/HO lamps at 120 input volts. This rapid start ballast has a maximum wattage rating of 282 watts and can operate up to 20 feet of fluorescent lighting. CSA and UL listed, this ballast is perfect for operating external lighting for offices or signs as well as indoor lighting for large rooms.
Brochures & Spec Sheets
Warranty
Product Attributes
| Brand | Sola |
|---|---|
| MPN (Part No.) | E620-F-2345088-TP |
| Lighting Technology | Fluorescent |
| UL Listed | Type 2 Outdoor |
| Voltage | 120 |
| Lamps Operated | (4) Lamps |
| Lamp Footage (Max) | 20 ft. |
| Lamp Footage (Min) | 6 ft. |
| Start Temp. (Min) | -20 Deg. F |
| Power Factor | 98% |
|---|---|
| Start Method | Rapid Start |
| THD | 42% |
| CSA Listed | Yes |
| Length | 12 in. |
| Height | 3 in. |
| Width | 3.2 in. |
| Weight | 11 lbs. |
| Warranty | 3-Year Limited |
