LED Canopy Light - 42 Watt - 2600 Lumens - 5161K Stark White - 120/277 Volt - AC Electronics AC-106/36/350
Additional Media

LED Canopy Light - 2600 Lumens - 42 Watt - 150W Equal

5161 Kelvin - Bronze Finish - AC Electronics AC-106/36/350



Energy Saving Calculator

LED Replacement     Watts
Existing Lamp     Watts
Lamps Replaced
Cost per kWh
Savings over life of lamp:   $0

Energy Savings / ROI Calculator close X

Calculate the total kilowatts saved by replacing the inefficient lamps with more efficient lamps

Original Lamp Wattage
Replacement Lamp Wattage X
Watts Saved Per Lamp =
Number of Lamps to Replace X
Total Watts Saved =
Total Kilowatts Saved =

Calculate the total kWh per year saved

Total Kilowatts Saved
Enter Hours Used Per Day X
Enter Days Used Per Week X
Enter Weeks Used Per Year X
Total kWh Saved Per Year =

Calculate the total energy cost saved per year

Total Kilowatts Saved Per Year
Energy Cost Per kWh X
Total Energy Cost Savings Per Year =

Payback on Investment

Initial Cost of Lighting Upgrade $
Total Energy Cost Savings Per Year /
Number of Months for Payback on Investment =
Savings over life of lamp =
Save energy and prevent light pollution with this LED canopy light. Using only 42 watts, this fixture produces 2,600 lumens, the equivalent of a 150 watt metal halide fixture. The die-cast aluminum, UL approved SM106 weatherproof housing encloses a 5161K Cree LED array and high-power LED driver. Easily wire the canopy light to an existing junction box in under 10 minutes for 50,000 hours of energy-saving commercial lighting. This Made in the USA fixture carries a 5 year warranty.

Features

Kit Includes:

  • Two-Output Channel, Class 2 LED Driver, Model Number: AC-D18C350UVH
  • Aluminum LED Driver Bracket
  • 2 PCB LED Array with 32 CREE MX-3 LEDs
  • Installation/Assembly Instructions
  • All Required Assembly and Mounting Hardware
  • Grandlite SM012 Fixture Housing

Brochures & Spec Sheets

Specifications

Stock Code:  LEDF-SM01236350
Family:  Minuteman 5
Wattage:  42 Watt
Color Temperature:  5161 Kelvin
Length:  12.4 in.
Height:  8.9 in.
Metal Halide Equal:  150 Watt
Life Hours:  50,000
Lumens (Initial):  2600
Made in USA:  Yes
Start Temp. (Min):  -40 Deg. F
Lens:  Polycarbonate
RoHS:  Compliant
Warranty:  5 Years


Brand:  AC Electronics
Part No.:  AC-012/36/350
Voltage:  120/277
CRI:  73.4
Width:  12.4 in.
Finish:  Bronze
Housing:  Die Cast Aluminum
Light Source:  LED
Lumens Per Watt:  58
Number of LEDs:  32
Start Temp. (Max):  110 Deg. F
THD:  15%
UL Listed:  Yes


Video

Customer Reviews

Rated 5 out of 5 by 4 reviewers.
Rated 5 out of 5 by Excellent product This is really a very good product. i bought 4 lights to begin with and ended up buying 12 and may order 2 more. Got referred by a friend and he loved it so we also tried. It is really easy to install and looks great in canopy. We dont know if we are saving any money of bills yet but i'm sure its LED so we should save some. November 11, 2013
Rated 5 out of 5 by Easy to install and excellent light ouput This product is very easy to install and customer is very happy with these fixtures. March 19, 2013
Rated 5 out of 5 This product is just same as mentioned Taken me a 1.5 hr to put together to put in my Carwash Bay and working very good. February 14, 2013
Rated 5 out of 5 by Met all expetations I was toying around with the idea of installing these lights in my pole building. I purchased 1 light to see if it would do the job. I hung the light at 12ft high and emits a useable amount of light. This light works so good I will be ordering 7 more. Best bang for the buck that I have found so far January 25, 2013
1-4 of 4
