Intermatic K4123C - Photo Control
Thermal Type Photocell - Stem Mounting - Dusk-To-Dawn - 208-277 Volt
Brochures & Spec Sheets
Installation Instructions
| MPN (Part No.) | K4123C |
| Width | 1.56 in. |
| Voltage | 208/240/277 |
| Length | 3 in. |
| Mounting | Stem |
| Start Temp. (Max) | 150 Deg. F |
| Depth | 1.56 in. |
| Case Quantity | 12 |
| Watts Ballast | 1700-2300 |
| Watts Tungsten | 3100-4150 |
| CSA Listed | Certified |
| Start Temp. (Min) | -40 Deg. F |
| UPC | 078275029590 |
| Brand | Intermatic |
| CA Title 20 | Compliant |
| Safety Rating | UL Indoor/Dry Location |
| Height | 3 in. |
| Maximum Current | 15 Amps |
| CA Title 24 | N/A |
Description
This Intermatic K4123C thermal type photo control provides dusk-to-dawn lighting controls of security lights, billboard lights, walkway lights, parking lot lights, and flood lights and features a delay action, which prevents your lights from switching off due to lightning or car headlights. The unit works on 208-277 volt systems and also features a dual-temperature compensating bi-metal and composite resistor to withstand temperature extremes.
- Completely protected from the elements, includes a sonic-welded polycarbonate case lens
- Standard 1/2 in. stem and 6 in. leads for safe and secure mounting
- Functions in temperatures from -40 to 158 degrees Fahrenheit
- Features light level slide
Not compatilbe with LED Fixtures
