    LEDF-AC32CD105AQBAW
    New LED Panels
    LED Driver - Operates 15-32 Watts - 10-30V Output Image
    LED Driver - Operates 15-32 Watts - 10-30V Output Image

    LED Driver - Operates 15-32 Watts - 10-30V Output

    500-1050mA Output Current with Switch Option - Dimmable - 120-277V Input - Works With Constant Current Products Only - AC Electronics AC32CD1.05AQBAW


    Product Image
    $25.03 ea
    An error has occurred
    LEDF-AC32CD105AQBAW

    LED Driver - Operates 15-32 Watts - 10-30V Output

    500-1050mA Output Current with Switch Option - Dimmable - 120-277V Input - Works With Constant Current Products Only - AC Electronics AC32CD1.05AQBAW

    Description

    AC Electronics Switch-Hitter constant current LED drivers feature an on-board current selection that includes adjustable current switching and dimming capabilities. The AC32CD1.05AQBAW 32-watt driver offers up to four different output currents: 500, 700, 950, or 1050mA. With a life rating of up to 100,000 hours, this driver is a consistent and efficient solution for your LED lighting system.

    • Suitable for outdoor environments with dust and jets of water
    • For use with constant current, high power LEDs
    • Input voltage range of 120-277VAC
    • Output voltage range of 10-30VDC
    • Output power of 15-32 Watts
    • Input frequency of 50-60Hz

    Professional Installation Recommended

    Comparable Products

    LED Driver - Operates 15-32 Watts - 10-30V Output Image LED Driver - 50 Watt - 1500mA Output Current Image LED Driver -  Operates 7-12 Watts -  3-36V Output Image LED Driver - Dimmable - 29 Volt - 20-40 Watts - 700-1400mA Output Current Image LED Driver - Operates 25-50 Watts - 25-36V Output Image
    Description LED Driver - Operates 15-32 Watts - 10-30V Output LED Driver - 50 Watt - 1500mA Output Current LED Driver - Operates 7-12 Watts - 3-36V Output LED Driver - Dimmable - 29 Volt - 20-40 Watts - 700-1400mA Output Current LED Driver - Operates 25-50 Watts - 25-36V Output
    Price $25.03 $17.51 $20.23 $26.18 $27.55
    SKU LEDF-AC32CD105AQBAW PLT-10703 LEDF-LCA012LU LEDF-AC40CD14UVQS LEDF-AC50CD14UVTS
    Brand AC Electronics Sosen Hatch AC Electronics AC Electronics
    MPN (Part No.) AC32CD1.05AQBAW SS-50R-36 LCA012-L-UNI AC-40CD1.4UV-QS AC-50CD1.4UV-TS
    Current Item
    An error has occurred
    An error has occurred
    An error has occurred
    An error has occurred

    Specifications

    Brand:AC Electronics
    MPN (Part No.):AC32CD1.05AQBAW
    Family:Switch Hitter
    Dimmable:Yes
    IP Rating:IP-66
    Safety Rating:UL Class 2/UL Indoor/Outdoor
    Life Hours:100,000
    Maximum Wattage:32 Watt
    Minimum Wattage:15 Watt
    Input Voltage:120/277
    Mounting:Bottom Lead
    Start Temp. (Min):-40 Deg. F
    Output Voltage:10-30 Volt
    Efficiency:up to 84%
    Power Factor:0.90
    Length:4.37 in.
    Height:1.26 in.
    Width:3.07 in.
    Weight:1.17 lb.
    Warranty:5 Years
    Case Quantity:20
