    RAB-ALED20
    LED Panels & Troffers
    1401 Lumens - 20 Watt - LED Area Flood Light Fixture Image
    1401 Lumens - 20 Watt - LED Area Flood Light Fixture Image
    1401 Lumens - 20 Watt - LED Area Flood Light Fixture Image
    1401 Lumens - 20 Watt - LED Area Flood Light Fixture Image
    1401 Lumens - 20 Watt - LED Area Flood Light Fixture Image
    1401 Lumens - 20 Watt - LED Area Flood Light Fixture Image

    1401 Lumens - 20 Watt - LED Area Flood Light Fixture

    120-277V - Bronze Finish


    Product Image
    An error has occurred
    Not for Sale. Reference Only.
    RAB-ALED20

    1401 Lumens - 20 Watt - LED Area Flood Light Fixture

    120-277V - Bronze Finish

    Comparable Products

    1401 Lumens - 20 Watt - LED Area Flood Light Fixture Image 2,700 Lumens - 30 Watt - LED Flood Fixture Image 19W - LED - Flood Fixture Image 2,105 Lumens - 19 Watt - LED Flood Light Fixture Image 3,989 Lumens - 37 Watt - LED Flood Light Fixture Image
    Description 1401 Lumens - 20 Watt - LED Area Flood Light Fixture 2,700 Lumens - 30 Watt - LED Flood Fixture 19W - LED - Flood Fixture 2,105 Lumens - 19 Watt - LED Flood Light Fixture 3,989 Lumens - 37 Watt - LED Flood Light Fixture
    Price $320.00 $103.90 $162.95 $172.00 $265.33
    SKU RAB-ALED20 LEDF-F201057943 LITH-0034 LITH-0114 LITH-0115
    Brand RAB Lighting PLT Lithonia Lighting Lithonia Lighting Lithonia Lighting
    MPN (Part No.) ALED20 JD-FLOODA301-02-WW DSXF1 LED 1 50K M4 DSXF1 LED 1 40K M4 DSXF1 LED 2 40K M4
    Current Item
    An error has occurred
    An error has occurred
    An error has occurred
    An error has occurred

    Brochures & Spec Sheets

    Description

    The RAB ALED20 high performance LED area flood lights are tested and certified to levels beyond industry standards. They are California Title 24 Compliant and exceed the Energy Star requirements for Color Stability during LM-80 testing. All RAB LED products have a 5 Year Warranty on the entire unit - LED, Driver, Finish, Performance - you name it!

    RAB Engineering can provide layout and energy savings assistance. Please contact your 1000Bulbs.com sales professional for assistance with these services.

    Specifications

    Brand:RAB Lighting
    MPN (Part No.):ALED20
    IDA Dark Sky:Compliant
    UL Listed:Wet Locations
    CRI:70
    Color Temperature:5000 Kelvin
    Life Hours:100,000
    Wattage:20 Watt
    Lumens:1401
    Voltage:277/120/208/240
    Finish:Bronze
    Metal Halide Equal:50 Watt
    Housing:Die Cast Aluminum
    Light Source:LED
    Start Temp. (Min):-40 Deg. F
    Start Temp. (Max):122 Deg. F
    THD:8.4%
    Height:2.375 in.
    Width:9.5 in.
    Depth:11.25 in.
    Weight:5.1 lbs.
    Warranty:5 Years
    Case Quantity:12

    Features

    • High Output LED Light Engine
    • Maintains 70% of initial lumens at 50,000 hours
    • Weatherproof high temperature silicone gaskets
    • Superior Heat Sinking with Die Cast Aluminum Housing and External Fins
