Magnetic Sign Ballast - 20-40 ft. Total Lamp Length - (2-4 Lamps)
120 Volt - Hatch GSB-2040-24-120
SKU:
BH-GSB204024120
No pricing information found.
Details
Description
Operates: F120T12/HO lamps
The Hatch GSB-2040-24-120 magnetic sign ballast features rapid start circuitry, is RoHS compliant, and can be used with up to (2) T12/HO 800mA lamps. This thermally protected, UL Type 2 listed ballast operates at 120 volts and has standard mounting holes and extra long leads for easy installation.
Brochures & Spec Sheets
Warranty
Product Attributes
| Brand | Hatch |
|---|---|
| MPN (Part No.) | GSB-2040-24-120 |
| UPC | 797281915047 |
| Lighting Technology | Fluorescent |
| UL Listed | Type 2 Outdoor |
| Voltage | 120 |
| Lamps Operated | (4) Lamps |
| Lamp Footage (Max) | 40 ft. |
| Lamp Footage (Min) | 20 ft. |
| Start Temp. (Min) | -20 Deg. F |
|---|---|
| Power Factor | 97% |
| Start Method | Rapid Start |
| Type | Magnetic Fluorescent |
| Length | 19.19 in. |
| Height | 2.63 in. |
| Width | 3.19 in. |
| Weight | 22.8 lb. |
| Warranty | 3-Year Limited |
