Advance SmartMate HDF226T435M
(2) Lamp - 26 Watt CFL - Electronic Ballast - 120/277 Volt - Programmed Start - 1.0 Ballast Factor - Dimming
SKU:
BA-HDF226T435M
No pricing information found.
Details
Description
Offering maximum versatility, the Philips Advance family of SmartMate ballasts for 4-pin compact fluorescent lamps drive a broad range of fluorescent lamps. The Advance HDF226T435M electronic fluorescent ballast operates (2) 26-watt CFL lamps at 120/277 input volts. HDF ballasts provide high-performance, full range dimming of linear and compact fluorescent lighting. Ideal for use in aesthetic and architectural dimming in residential and commercial spaces.
Brochures & Spec Sheets
Advance HDF226T435M Spec Sheet
Product Attributes
| Brand | Advance |
|---|---|
| MPN (Part No.) | HDF226T435M |
| UPC | 781087111321 |
| Lighting Technology | CFL |
| Family | SmartMate |
| Dimmable | Yes |
| UL Listed | Yes |
| Voltage | 120 |
| Ballast Factor | 1 |
| Lamps Operated | (2) Lamps |
| Start Temp. (Min) | 0 Deg. F |
| Power Factor | 98% |
|---|---|
| Start Method | Programmed Start |
| THD | 10% |
| Type | Electronic Fluorescent |
| CSA Listed | Yes |
| Length | 5 in. |
| Height | 1.18 in. |
| Width | 3 in. |
| Weight | 0.9 lbs. |
| Warranty | 5-Year Limited |
