Advance SmartMate HDF226T435M

Advance SmartMate HDF226T435M - (2) Lamp - 26 Watt CFL - Electronic Ballast - 120/277 Volt - Programmed Start - 1.0 Ballast Factor - Dimming

Advance SmartMate HDF226T435M Image
Advance SmartMate HDF226T435M Image
Advance SmartMate HDF226T435M Image
Advance SmartMate HDF226T435M Image
Advance SmartMate HDF226T435M Image

Advance SmartMate HDF226T435M

Advance SmartMate HDF226T435M - (2) Lamp - 26 Watt CFL - Electronic Ballast - 120/277 Volt - Programmed Start - 1.0 Ballast Factor - Dimming

Offering maximum versatility, the Philips Advance family of SmartMate ballasts for 4-pin compact fluorescent lamps drive... View More Details

Product Image
An error has occurred
Not for Sale. Reference Only.
SKU: BA-HDF226T435M

See Similar Products
Brand:Advance
MPN (Part No.):HDF226T435M
UPC:781087111321
Family:SmartMate
Dimmable:Yes
UL Listed:Yes
Voltage:120
Ballast Factor:1.0
Lamps Operated:(2) Lamps
Start Temp. (Min):0 Deg. F
Power Factor:98%
Start Method:Programmed Start
THD:10%
Type:Electronic Fluorescent
CSA Listed:Yes
Length:5 in.
Height:1.18 in.
Width:3 in.
Weight:0.9 lb.
Warranty:5 Years

Description

Offering maximum versatility, the Philips Advance family of SmartMate ballasts for 4-pin compact fluorescent lamps drive a broad range of fluorescent lamps. The Advance HDF226T435M electronic fluorescent ballast operates (2) 26-watt CFL lamps at 120/277 input volts. HDF ballasts provide high-performance, full range dimming of linear and compact fluorescent lighting. Ideal for use in aesthetic and architectural dimming in residential and commercial spaces.
