ZTS MBT-1 - Multi-Battery Tester

For More Than 30 Battery Types

ZTS MBT-1 - Multi-Battery Tester Thumbnail
ZTS MBT-1 - Multi-Battery Tester Thumbnail
ZTS MBT-1 - Multi-Battery Tester Thumbnail

The ZTS Multi-Battery Tester (MBT-1) provides a comprehensive means of testing the state of charge or state of power for more than 30 battery types. This microprocessor-controlled instrument is designed for commercial or home use and tests popular primary (non-rechargeable) and rechargeable batteries using a patented, high accuracy pulse load test.

Requires 4 "AA" batteries (not included).

View More Details

Product Image
$107.46 ea.
An error has occurred
SKU: ZTS-MBT1-2ND

Lighting can be confusing! Expert Help - Call Now
1-800-624-4488

The ZTS Multi-Battery Tester (MBT-1) provides a comprehensive means of testing the state of charge or state of power for more than 30 battery types. This microprocessor-controlled instrument is designed for commercial or home use and tests popular primary (non-rechargeable) and rechargeable batteries using a patented, high accuracy pulse load test.

Requires 4 "AA" batteries (not included).

Brochures & Spec Sheets

Brand ZTS, Inc.
MPN (Part No.) MBT-1
Made in USA Yes
UPC 856777000169
Display 6 LEDs
Warranty 1 Year
Weight 0.875 lb.
Battery Type NiMH, Li-Ion, Alkaline, Lithium, Coin Cell, Button Type
Depth 1.25 in.
Height 8 in.
Width 4.5 in.
Safety Rating N/A

Description

The ZTS Multi-Battery Tester (MBT-1) provides a comprehensive means of testing the state of charge or state of power for more than 30 battery types. This microprocessor-controlled instrument is designed for commercial or home use and tests popular primary (non-rechargeable) and rechargeable batteries using a patented, high accuracy pulse load test.

Requires 4 "AA" batteries (not included).

Features

  • Computes State of Charge (SOC) for more than 30 battery types
  • Easy to use - no switches or settings
  • Test battery condition - quickly and easily identifies weak or failing batteries
  • Patented high accuracy Pulse Load test - battery safe, non-invasive
  • Measures battery performance under load, not just voltage or internal resistance
  • Ideal for battery management and cell matching - reduce costs and increase reliability
  • Made in U.S.A. Patents 6,823,274 and D569285

Testing Capabilities

  • 3.6v Li-Ion rechargeable [RCR123A, 18500, 17650, 18650](non-regulated type)
  • 1.5v button cell [S76, A76, A625, A640, LR44, 357, 303]
  • 1.2v NiMH/NiCd rechargeable [AA, AAA, C, D]
  • 1.5v lithium [AA L91, AAA L92]
  • 3v lithium coin [CR1216, CR1220, CR1232, CR1612, CR1616, CR1620, CR1632, CR2016, CR2025, 58L, 1/3N] [CR2032, CR2320, CR2430, CR2450]
  • 6v '28' series [28A, S28, 28L, 544, 4LR44]
  • 3v lithium cylindrical [CR123, CR2,]
  • 1.5v alkaline [AA, AAA, C, D, N]
  • 12v alkaline [A23]
  • 9v alkaline, carbon zinc
